Indoor Air Quality    Model 1010A IAQ Meter
Loading
Measure ambient CO2, temperature, relative humidity, dew point, wet bulb, CO, and calculate percentage outside air. The TPI 1010A Indoor Air Quality (IAQ) Meter is a state of the art, easy to use tester designed to provide you with the necessary measurements to monitor and make adjustments to air handling devices.

The 1010A IAQ meter uses state of the art sensors to measure carbon dioxide (CO2), and temperature.
Calculate percent outside air to maintain acceptable CO2 levels in buildings and work spaces

Measure and display Carbon Dioxide (CO2) and Carbon Monoxide

Measure ambient air temperature

Measure relative humidity, dew point and wet bulb

Log up to 10,000 readings in 1 second to 1 hour intervals

Download to a computer using the A368 USB cable

New! Print via I/R to optional printer (Model A740)


TPI 1010
rollover to zoom


TPI Model 1010A Indoor Air Quality Meter

The 1010A IAQ meter uses state of the art sensors to measure humidity, carbon dioxide (CO2), and temperature. The instrument is ruggedly constructed and comes with a 3 Year unit and 2 Year sensor Guarantee.


The TPI 1010A Indoor Air Quality meter comes complete with the following standard accessories:

• TPI 1010A Instrument
• Protective Rubber Boot (A800)
• Soft Carrying Case (A921)
• USB Cable & Software (A803)
• Instruction Manual

Your TPI 1010A Indoor Air Quality meter has the following optional accessories available:
• Power adapter / Battery eliminator (A804)
• Magnetic strap kit to hang meter (A127)
• Boot hook to hang meter (A103)
• Replacement Software only (A802)
• Replacement USB cable only (A801)


C-UL-US     CE Marking


Download Data Sheet PDFDownload Product Manual PDF

 Model 1010A IAQ Meter Specifications
 Function: CO2  Range: 0 to 5000ppm
 Accuracy: 50°F~104°F: ±5% of rdg+75ppm
 <50°F, >104°F: ±10% of rdg+75ppm
 Function: Temperature  Range: -5°F to 140°F
 -20°C to 60°C
 Accuracy: ±2°F
 ±1°C
 Function: Dew Point Temperature  Range: -47°F to 135°F
 -44°C to 57°C
 Accuracy: Calculation
 ±1°C
 Function: Wet Bulb Temperature  Range: 3°F to 135°F
 -16°C to 57°C
 Accuracy: Calculation
 Function: Relative Humidity  Range: 5% to 95%
 Accuracy: ±2°F
 ±1°C
 Function: CO  Range: 0 to 500ppm
 Accuracy: ±3ppm or ±5% of rdg whichever is greater
 Function: % Outside Air  Range: 0 to 100%
 Accuracy: Calculation
 Data Logging  Up to 4,000 samples 1 sec to 23hr 59min interval
 Display Type  3 line with annunciators and backlight
 CO2 Alarm  Audible and visual, selectable level (factory default 30ppm)
 Operating Temperature & Humidity  CO and CO2: 14°F to 122°F (-10°C to 50°C)
 All Other Function: -4°F to 140°F (-20°C to 60°C)
 Humidity 15 ~ 95% non-condensing
 Storage Temperature  -4°F to 140°F (-20°C to 60°C)
 Power supply  3 AA batteries ( 4.5V)
 AC/DC adapter 5Vout (Center positive)
 Battery Life: 40 hours typical without backlight
 Output  Serial output via USB connection
 Infrared output to optional A740 printer



Model 1010A Applications
• Check ambient CO and CO2 levels in work and living spaces
• Monitor results of air control systems
• Ambient air temperature and humidity
• Test dew point and wet bulb humidity



TPI Model 1010A IAQ Meter Demonstration Video
